Olide WiFi Smart Residential Swing Door Operator Manufacturer
Olide tuya wifi smart automatic swing door opener is a smart device that can be controlled with a mobile app and smart speakers Echo,Google home;
The automatic swing door opener operates in both automatic and manual modes. In manual mode, door opens with very little pressure and closes slowly providing easy operation for handicapped or pedestrians.
- Olide-120b swing door opener is wide voltage design AC100-240V, for worldwide use;
- Can be install on single and double doors,Max. single door weight up to 120kg; and both can inswing open&outswing open with push and pull arm;
- The controller has a built-in intelligent imported chip, which can keep the door opener in the best condition at all times;
- Equipped with hand-held debugging equipment, the debugging parameters are simple and convenient, the door opening speed, door closing force, holding time, etc. can be adjusted with the programmer;
- 100% wireless remote control, remote control of the door opener, compact and easy to carry;
- Smart swing door operator can be controlled by "tuyasmart" app, and can link with Echo, google home assistant; other home smart device also can be controlled together, such as air conditioner, TVs, lights, etc..
Technical Parameters
Voltage: | 110-220 VAC +/-10% |
Motor: | DC 24V brushless motor |
Power Consumption: | 50W |
Opening Time: | 3-7 sec. @ 90 degrees |
Hold Open Time: | 1-30 sec. Adjustable |
Max. Door Frame Depth: | 450mm / 17.7" |
Door Width: | Max. 1200mm / 47.2" Min. 660mm / 26" |
Max. Opening Angle: | 120 degrees |
Environment Temperature: | -20C to 50C -4F to 122F |
Operation Noise: | Less than 55db |
Opener Size: | 21.45''(L)*3.35''(W)*3.74''(H) |
Opener Weight: | 9.5kg/ 20.9 LBS |
